Force analysis and structure optimization of chain link of chain scraper conveyor

Date: 2021-05-14     Tag:  chain scraper conveyor scraper conveyor scraper chain conveyor     Tag:  Browsing volume:936

The chain link of the chain scraper conveyor is widely used in mining transportation equipment, and the chain link is the core of the normal operation of the entire equipment.

The chain link of the  scraper chain conveyor is the connecting part on the scraper chain of the coal mine scraper conveyor. It plays an important role in the traction chain. Due to the special working conditions, the chain link often breaks during traction. Once the chain link is broken, the entire equipment is in a state of paralysis, which seriously affects the normal production of the coal mine. Not only has the economy suffered serious losses, but the search for broken links and connecting links are all carried out on the side of the coal wall, which is dangerous and may even cause personal accidents. The chain link has a high breaking capacity and requires high reliability in work.

The previous analysis of the chain link of the  scraper chain conveyor did not consider the influence of the cylindrical pin, but in fact the role of the pin must not be ignored. For example, if you pull a rubber band hard, the middle part is obviously concave and thinner. The function of the pin is equivalent to exerting a supporting force of a vertical acting surface and an additional moment to prevent the middle part of the connecting link from becoming thinner inwardly.
